Hardware Parameter
|
|
Working voltage
|
12V
|
Input voltage
|
3S ~ 6S
|
Output voltage
|
5V (connect with PWM)
|
Dynamic current
|
650~850mA @ 12V
|
Idle current
|
650mA @ 12V
|
Working environment temp.
|
-20℃ ~ +60℃
|
Output
|
micro HDMI(1080P 50fps) / IP (1080p/720p)
|
Local-storage
|
TF card (Up to 128G, class 10, FAT32 or ex FAT format)
|
Photo storage format
|
JPG(1920*1080/1280*720)
|
Video storage format
|
MP4 (1080P/720P 25fps/30fps)
|
Control method
|
PWM / TTL / S.BUS / TCP(IP output)
|
Gimbal Spec
|
|
Mechanical range
|
Pitch/Tilt: -70~120°, Roll: ±55°, Yaw/Pan: ±300° / ±360°*N (IP output version)
|
Controllable range
|
Pitch/Tilt: -45°~90°, Yaw/Pan: ±290° / ±360°*N (IP output version)
|
Vibration angle
|
Pitch/Roll: ±0.02°, Yaw:±0.02°
|
One-key to center
|
√
|
Thermal Imager Spec 1
|
|
Lens size
|
52mm
|
Horizontal FOV
|
11.9°
|
Vertical FOV
|
9°
|
Diagonal FOV
|
14.9°
|
Detective Distance (Man: 1.8x0.5m)
|
1529 meters
|
Recognize Distance (Man: 1.8x0.5m)
|
382 meters
|
Verified Distance (Man: 1.8x0.5m)
|
191 meters
|
Detective Distance (Car: 4.2x1.8m)
|
4690 meters
|
Recognize Distance (Car: 4.2x1.8m)
|
1173 meters
|
Verified Distance (Car: 4.2x1.8m)
|
586 meters
|
Working mode
|
Uncooled long wave (8μm~14μm) thermal imager
|
Detector pixel
|
640*480
|
Pixel size
|
17μm
|
Focusing method
|
Athermal prime lens
|
Emissivity correction
|
0.01~1
|
NETD
|
≤50mK (@25℃)
|
MRTD
|
≤650mK (@characteristic frequency)
|
Image enhancement
|
Auto adjust image brightness and contrast ratio
|
Color palette
|
White, iron red, pseudo color
|
Auto Non-uniform correction
|
Yes (no shutter)
|
Digital zoom
|
1x ~ 4x
|
Sync correct time
|
Yes
|
Thermal Imager Spec 2
|
|
Lens size
|
13mm
|
Horizontal FOV
|
45.4°
|
Vertical FOV
|
34.8°
|
Diagonal FOV
|
55.2°
|
Detective Distance (Man: 1.8x0.5m)
|
382 meters
|
Recognize Distance (Man: 1.8x0.5m)
|
96 meters
|
Verified Distance (Man: 1.8x0.5m)
|
48 meters
|
Detective Distance (Car: 4.2x1.8m)
|
1173 meters
|
Recognize Distance (Car: 4.2x1.8m)
|
293 meters
|
Verified Distance (Car: 4.2x1.8m)
|
147 meters
|
Working mode
|
Uncooled long wave (8μm~14μm) thermal imager
|
Detector pixel
|
640*480
|
Pixel size
|
17μm
|
Focusing method
|
Athermal prime lens
|
Emissivity correction
|
0.01~1
|
NETD
|
≤50mK (@25℃)
|
MRTD
|
≤650mK (@characteristic frequency)
|
Image enhancement
|
Auto adjust image brightness and contrast ratio
|
Color palette
|
White, iron red, pseudo color
|
Auto Non-uniform correction
|
Yes (no shutter)
|
Digital zoom
|
1x ~ 4x
|
Sync correct time
|
Yes
|
Thermal Object Tracking
|
|
Update rate of deviation pixel
|
50Hz
|
Output delay of deviation pixel
|
5ms
|
Minimum object contrast
|
5%
|
SNR
|
4
|
Minimum object size
|
32*32 pixel
|
Maximum object size
|
128*128 pixel
|
Tracking speed
|
32 pixel/frame
|
Object memory time
|
100 frames (4s)
|
The mean square root values of pulse noise in the object position
|
< 0.5 pixel
|
Packing Information
|
|
N.W.
|
720g
|
Product meas.
|
127.5*155.3*126.6mm
|
Accessories
|
1pc gimbal camera device, 16pcs screws, 4pcs copper cylinders, 12pcs damping balls, 4pcs damping boards, 1pc USB to TTL cable /
Hight quality plastic box with foam cushion |
G.W.
|
1830g
|
Package meas.
|
300*250*200mm
|
