Hardware Parameter
|
|
|
Working voltage
|
12V
|
|
Input voltage
|
3S ~ 6S
|
|
Output voltage
|
5V (connect with PWM)
|
|
Dynamic current
|
750mA @ 12V
|
|
Idle current
|
550mA @ 12V
|
|
Working environment temp.
|
-20℃ ~ +60℃
|
|
Output
|
micro HDMI(1080P 60fps) / IP (720p) / SDI (1080P 30fps)
|
|
Local-storage
|
SD card (Up to 128G,class 10, FAT32 or ex FAT format)
|
|
Control method
|
PWM / TTL / S.BUS/ TCP (IP output version)
|
|
Control method
|
PWM / TTL / S.BUS
|
|
Gimbal Spec
|
|
|
Angle scope of structure design
|
Pitch/Tilt: -100°～120°, Roll: ±70°, Yaw/Pan: ±300° / ±360°*N (IP output version)
|
|
Angle scope of software design
|
Pitch/Tilt: -45°～90°, Yaw/Pan: ±290° / ±360°*N (IP output version)
|
|
Vibration angle
|
Pitch/Roll: ±0.02°, Yaw：±0.02°
|
|
One-key to center
|
√
|
|
Camera Spec
|
|
|
Imager Sensor
|
SONY 1/2.8" "Exmor R" CMOS
|
|
Picture quality
|
Full HD 1080 (1920*1080)
|
|
Effective pixel
|
2.13MP
|
|
Photo storage format
|
JPG(1920*1080)
|
|
Video storage format
|
MP4 (1080P/720P 25fps/30fps)
|
|
Lens optical zoom
|
30x, F=4.3~129mm
|
|
Digital zoom
|
12x (360x with optical zoom)
|
|
Min object distance
|
10mm(wide end) to 1200mm(tele end). Default 300mm
|
|
Horizontal viewing angle
|
1080p mode: 63.7°(wide end) ~ 2.3°(tele end)
|
|
720p mode: 63.7°(wide end) ~ 2.3°(tele end)
|
|
|
SD: 47.8°(wide end) ~ 1.7°(tele end)
|
|
|
Sync system
|
Internal
|
|
S/N ratio
|
more than 50dB
|
|
Min illumination
|
Color 0.01lux@F1.6
|
|
Exposure control
|
Auto, Manual, Priority mode(shutter priority & iris priority), Bright, EV compensation, Slow AE
|
|
Gain
|
Auto/Manual 0dB to 50.0dB(0 to 28 steps + 2 setep/ total 15 steps)
Max.Gain Limit 10.7 dB to 50.0dB (6 to 28 steps + 2 step/ total 12 steps) |
|
White balance
|
Auto, ATW, Indoor, Outdoor, One Push WB, Manual WB, Outdoor Auto, Sodium Vapor Lamp (Fix/
Auto/Outdoor Auto) |
|
Shutter speed
|
1/1s to 1/10,000s, 22 steps
|
|
Backlight compensation
|
Yes
|
|
Aperture control
|
16 steps
|
|
Defog
|
Yes
|
|
OSD
|
Yes
|
|
Camera Object Tracking
|
|
|
Update rate of deviation pixel
|
50Hz
|
|
Output delay of deviation pixel
|
5ms
|
|
Minimum object contrast
|
5%
|
|
SNR
|
4
|
|
Minimum object size
|
32*32 pixel
|
|
Maximum object size
|
128*128 pixel
|
|
Tracking speed
|
32 pixel/frame
|
|
Object memory time
|
100 frames (4s)
|
|
The mean square root values of pulse noise in the object position
|
< 0.5 pixel
|
|
Packing Information
|
|
|
N.W.
|
876g
|
|
Product meas.
|
121.5*166.5*130mm
|
|
Accessories
|
1pc gimbal camera device, screws, copper cylinders, damping balls, damping boards / Hight quality plastic box with foam cushion
|
|
G.W.
|
3058g
|
|
Package meas.
|
360*300*250mm
|
